Large Dog Wide Cage
Hover to display dimensions
With a 750mm depth and 1080mm width, the Large Dog Wide Cage (formerly "Slimline" / "Extra Wide") is the same depth but wider than the Large Dog Cage and will house Rottweillers and Labradors, etc.
When installed with a row of Cat or Small Dog cages (650mm depth) on top, there is little waste space at the rear of the cage bank.
However, a greater width dimension means that the door swings further out into the room, making it less suitable for long, narrow wards.
Cage Dimensions
Width
1090 mm*
Height
960 mm*
Depth
750 mm
Floor Area
0.75 m2
* Width and height dimensions include a nominal 45mm wide flange surrounding the cage.
Door Specifications
Perimeter bar thickness
8.0 mm
Vertical bar thickness
5.0 mm
On-center vertical bar spacing
50.0 mm
